Crosscut dual shaft shredders utilize intermeshing blade sets to slice, shear, and shred materials bi-directionally. This mechanism delivers a finer and more uniform output, reducing the need for secondary size reduction. Built for heavy-duty applications, these machines are suitable for e-waste, metals, hard plastics, and multi-layered packaging.
Designed with robust gear-driven systems and advanced overload protection, these shredders offer long operational life with low maintenance cycles. Their ability to handle mixed and contaminated input makes them ideal for complex industrial waste streams.
| Feed Opening | 1000mm |
|---|---|
| Motor HP/Kw | 30.0 HP / 22.5 kW |
| Voltage | 415 V / 50 Hz / 3 Phase / (3P + N + E) |
| Through Put | 800 - 1000 Kgs Per Hour |
| Output Size | Uneven Shred Size |
| Feeding Mechanism | Manually Feeding |
| Machine Weight | 1650kgs (Approx.) |
| Shredder Type | Dual Shaft Cross Cut Shredder |
|---|---|
| Cutting Head Opening | 1000mm |
| Cutter Diameter | 225mm |
| Cutter Thickness | Thickness Of 12mm / 15mm / 19mm / 24mm |
| Note | Cutter Thickness Depends On Product/Material To Shred and Required Output |
| Cutter | C45Mn75 Grade Cutter Duly Hardened |
| Shaft | C55Mn75 Alloy Steel - 2nos w/ Hex Machining @75mm A/F For Firm Grip On Cutters For Zero Slippage |
| Gearbox | Kavitsu / Power Build |
| Gear | C55Mn75 Hardened With Spline For Zero Slippage |
| Motor | Hindustan / Siemens / Crompton |
| Scrapper | Mild Steel Duly Machining Done |
| Machine Frame | Heavy 'C' Channel Of Mild Steel Duly Powder Coated |
