Shred Maxx is a major manufacturer of shredders in India and deals with high performance PET Bottle Shredder and Plastic Bottle Shredder Machines. Our shredders are designed using heavy-duty materials and cutting systems that are highly accurate thus guaranteeing consistency in production, minimal downtimes and longevity. They can handle a huge range of plastic products, such as bottles of PET, HDPE, PP, and PVC, without losing efficiency or ensuring safety.
Our PET bottle shredders are offered in Twin Shaft and Double Shaft models that offer flexibility to support production capacities and material type diversities. We also have strong double cutters that are hardened with alloy steel and thus they last longer. The shredders can work with both typical water bottle and soft drinks containers and with the industrial waste of packaging. It has a continuous feeding system that provides a smooth operation, minimizes jamming, and maximization of productivity even during processing of plastic objects that have a large volume or irregular shapes.
The design of our shredders is such that they can process large amounts of plastic waste. Our bottle shredders have been designed to operate continuously and are engineered to perform reliably, with durability and precision with the ever changing demands of recycling of plastic.
| Feed Opening | 500mm |
|---|---|
| Motor HP/Kw | 7.5 HP / 5.625 kW |
| Voltage | 415 V / 50 Hz / 3 Phase / (3P + N + E) |
| Through Put | 350 - 450 Kgs Per Hour |
| Output Size | Uneven Shred Size |
| Feeding Mechanism | Manually Feeding |
| Machine Weight | 1046kgs (Approx.) |
| Shredder Type | Dual Shaft Cross Cut Shredder |
|---|---|
| Cutting Head Opening | 500mm |
| Cutter Diameter | 225mm |
| Cutter Thickness | Thickness Of 12mm / 15mm / 19mm / 24mm |
| Note | Cutter Thickness Depends On Product/Material To Shred and Required Output |
| Cutter | C45Mn75 Grade Cutter Duly Hardened |
| Shaft | C55Mn75 Alloy Steel - 2nos w/ Hex Machining @75mm A/F For Firm Grip On Cutters For Zero Slippage |
| Gearbox | Kavitsu / Power Build |
| Gear | C55Mn75 Hardened With Spline For Zero Slippage |
| Motor | Hindustan / Siemens / Crompton |
| Scrapper | Mild Steel Duly Machining Done |
| Machine Frame | Heavy 'C' Channel Of Mild Steel Duly Powder Coated |
